Re: The Bent Zombie Tribrid Tadpole Trike (build phase)

Here's a few shots of the tray details, doesn't seem like much to fret over - but aside from my lil vacation, the reason they were a bit of a challenge becomes more clear as you can see in the pics it's a busy place w/o much room for location choices or error... in the last pic I've got the larger SLAs in place tho I'm obviously not going to use them unless the lifepo4 packs fail for w/e reason;



BarelyAWake

New Member
Jul 21, 2009
7,194
21
0
Maine
Re: The Bent Zombie Tribrid Tadpole Trike (build phase)

...and last but not least some gratuitous "glamor" shots, just cause :D



BarelyAWake

New Member
Jul 21, 2009
7,194
21
0
Maine
Re: The Bent Zombie Tribrid Tadpole Trike (build phase)

I'd weighed the individual components a while ago & it was about 126 pounds total, minus only little things I didn't have at the time such as the throttles, switches & wiring... so mebbe 130lbs? Seems like a lot I know - but on the other hand it's almost exactly the same weight as a new moped, less than many even :D

minus engines & batteries 49lbs
engines (both) 60lbs
lifepo4 packs 16.5lbs

The kicker was replacing the SLA batteries, which just by themselves weighed 34lbs... yet with roughly 1/2 the capacity of the lifepos >.<

Last edited:

BarelyAWake

New Member
Jul 21, 2009
7,194
21
0
Maine
Re: The Bent Zombie Tribrid Tadpole Trike (build phase)

I went an' ordered some more shiny bits, stuff I s'pose I don't really need... aw, ta heck w/it, want/need - what's the difference really? heh

Anyway, the exhaust system has far better flow than the stock can I've got on the taddy ATM given that one has an outlet about the size of a bic pen... but that's not really why I got it & in fact if it's too loud I'll prolly swap it back out again - I got it 'cause it's oval instead of round, which outa help narrow the taddy's width a bit for the panniers that are still in the planning stage. I'll most likely be cutting the chrome pipe off & using the steel one I've got... as I'm typing this I've realized I forgot to get the header wrap *sigh* ahh, next week mebbe lol;


Piranha 50 Pipe

Got this lil K&N style air filter - but only because I've not found a suitable remote airbox yet, which when I do will go on the opposite side of the muffler mount. It's good 'nuff for now tho I figure & when I do find/make an airbox I'll jus' stick the lil thing on the Rollfast I figure;


Trail Bikes Air Filter

...and I finally gave in to temptation and got the 'Vapor' digital gauge ('Stealth' the black one ofc) - it jus' had too much groovy factor to ignore with it's speedometer, tachometer and temperature gauges as well as a buncha other stuff I'll prolly never use lol Still, a speedo is a must & the tach & temp outa prove handy;


Vapor Digital Gauge

* Speedometer:
o Current Speed
o Maximum Speed
o Selectable MPH/KMH Display
* Tachometer:
o Real-Time RPM Bar Graph
o Numeric RPM Readout
o Dual Programmable Shift Lights
o Up to 20,000 RPM
* Temperature:
o Ambient Temperature
o Engine Temperature
o Dual Programmable Temp Lights
o Exact Model Fit Temperature Sensors
o Selectable °F/°C Display
* Distance:
o Adjustable Distance
o Permanent Odometer
o Selectable Mile/Kilometer Display
* Clock:
o Hour Meter
o Stop Watch
o Ride Time
o Accumulated Ride Time
o permanent Hour Meter
o Selectable 12/24 Hour Display
* Power Input:
o Includes Power Connection Fits All Machines
o Accepts Any Power Input - AC/DC
o Auto Switch to Internal Power if External is Removed
o Permanent Memory Guarantees Data is Never Lost
I went ahead and got the 'Indicator Dashboard' for it as well, tho I'm not 100% sure I'll be able to fit it where I wanna put it (couldn't find measurement specs), but I do have three possible locations so mebbe it'll work out. I do hope it does as I will be installing blinkers & whatnot... but mostly b'cause of the aforementioned "groovy factor" again;


Vapor Indicator Dashboard

Last edited:

BarelyAWake

New Member
Jul 21, 2009
7,194
21
0
Maine
Re: The Bent Zombie Tribrid Tadpole Trike (build phase)

...and I did manage to get some "work" done as well heh

The handlebars I'd made before weren't supposed to be just "mock ups" but they were jus' a lil wonky - as it turns out the left one was turned in just a tiny bit, which drove me nuts for a lil while trying to figure out why my seat could be perfectly centered... but not centered at the same time o_O I coulda fixed them I s'pose as they were still only tack welded, but I woulda hadta redo the fishmouth & they were already a lil too short, so I jus' made new ones.

What's interesting is while I'm not completely satisfied with the angle/shape, they're comfy enough and as the only other sacrificial handlebar candidate I had that was even remotely close to what I need was exactly the same as the first one I hacked up - I guess it's fate lol

Still a hair short I stuck 2" extensions on 'em too, which prolly makes them a tiny bit too tall now, but as it's far easier to trim them down than to extend them again I'll try 'em as is and see how they feel. Everything still clears at maximum turn so it's just a matter of ergonomics... or me being a picky SOB... six of one/half dozen of the other really I s'pose;



....and I'm outa semigloss black paint again aargh >.<


The_Aleman

Active Member
Jul 31, 2008
2,653
4
38
el People's Republik de Kalifornistan
Re: The Bent Zombie Tribrid Tadpole Trike (build phase)

Suh-weeet! Been drooling on the Vapor since last year. Build like yours deserves it!

In the meantime, you can picture the digital tach bar dancing while you make your vroom sounds! :D


BarelyAWake

New Member
Jul 21, 2009
7,194
21
0
Maine
Re: The Bent Zombie Tribrid Tadpole Trike (build phase)

Thanks Ale ;)

Picture the tach dancin'? Ya mean stare at this gif whilst I make vroomie noises to meself?



OMG I would nevvor, such slander o.o rotfl


BarelyAWake

New Member
Jul 21, 2009
7,194
21
0
Maine
Re: The Bent Zombie Tribrid Tadpole Trike (build phase)

Got the new handlebars (temp) painted & installed & did summore testing (read set on it & make vroomie noizes) & found out I'd installed the brake levers "backwards" this whole time... as in on the outside of the throttles instead if the inside. No big deal & easy 'nuff to fix - but if I'd left them that way it's possible to get "tangled" trying to grab just one lever, whereas this way it's easy as pie to jus' grab/let go as ya please, without fumbling or even lookin' at 'em - the other way "looked" better sure, but I figure panic stopping is prolly more important.

So, there's a point to vroomie noises after all lol

I also discovered a bit of a cause for concern - namely, at full extension/hardest turn me fingers/brake lever gets awful close to the upper A arm... I did some testing under full suspension compression and it shouldn't hit, but "shouldn't" doesn't fill me with confidence... so I reconfigured both the handlebars to be almost perfectly upright at neutral instead of canted forward, which moved the tips back three inches and gave me some wiggle room.

They're still very comfy, the added two inches in height helped a bunch with this, particularly the side furthest back in a hard turn. I may be overreacting in any case as I've the linkages set to maximum - furthest handlebar travel for the least wheel turn, for high speed stability & ofc testing purposes. It may well be that I've overcompensated and could have significantly less handlebar travel - but that too is easy enough to adjust, I've three "settings" on the linkage tabs for exactly that reason *shrug* Well see I s'pose ;)

I then messed around with wheel alignment a bunch as LF was always a bit wall eyed anyway, but it was a tedious & slow process that's not even worthy of some pics heh "hey look guys, I turned the tie rod a half turn out, then again... hey look I did it summore" :p

Still, it progresses FTW


Last edited:
