Ask a specific question

Discussion in 'Motorized Bicycle General Discussion' started by deacon, Jan 22, 2008.

  1. deacon

    deacon minor bike philosopher

    Joined:
    Jan 15, 2008
    Messages:
    8,119
    Likes Received:
    0
    I saw that norm, what I am working on is a logic for the story on my blog. If you are in a small town and the clutch cable breaks, could you go to a hardware store and make a lawn mower cable work till you got home. I think it would work well enough for a while at least. I think a good emergency list of "make do" stuff would be nice to have around.

  2. Norman

    Norman LORD VADER Moderator
    Staff Member

    Joined:
    Jan 16, 2008
    Messages:
    2,605
    Likes Received:
    1
    carry a special little cable end made with brass drilled and threaded and a length of
    1/16" flex aircraft cable which you can get at a hardware store, I can put up some pictures later if you would like.

    You guys want a how to on a cable end mold? Let me know, I'll show you all how to make one in the shop step by almost step
    Today so let me know.

    #42 Norman, Feb 10, 2008
    Last edited: Feb 10, 2008
  3. Bikeguy Joe

    Bikeguy Joe Godfather of Motorized Bicycles

    Joined:
    Jan 8, 2008
    Messages:
    11,529
    Likes Received:
    2
    Sounds like that would fit in the tool box/bag.

  4. deacon

    deacon minor bike philosopher

    Joined:
    Jan 15, 2008
    Messages:
    8,119
    Likes Received:
    0
    yes you need to show me what you are talking about. I don't have any idea what it looks like.

  5. Bikeguy Joe

    Bikeguy Joe Godfather of Motorized Bicycles

    Joined:
    Jan 8, 2008
    Messages:
    11,529
    Likes Received:
    2
    I think they are called a cable end clamps- I get them at the Tractor Supply Co. or Ace hardware.

    The end of the cable slips through the hole in it, then you tighten an allen head screw down on the cable.

  6. Bikeguy Joe

    Bikeguy Joe Godfather of Motorized Bicycles

    Joined:
    Jan 8, 2008
    Messages:
    11,529
    Likes Received:
    2
  7. Bikeguy Joe

    Bikeguy Joe Godfather of Motorized Bicycles

    Joined:
    Jan 8, 2008
    Messages:
    11,529
    Likes Received:
    2
    Well, that one has a regulat hex head bolt on it...

  8. Norman

    Norman LORD VADER Moderator
    Staff Member

    Joined:
    Jan 16, 2008
    Messages:
    2,605
    Likes Received:
    1
    I can show down and dirty cable clamp then a how to on a mold to cast cable ends sound like fun? I can also do an end for the throttle I've shown that on here before.
    What about shorter cable need a show how on that?

  9. Norman

    Norman LORD VADER Moderator
    Staff Member

    Joined:
    Jan 16, 2008
    Messages:
    2,605
    Likes Received:
    1
    Deacon
    Your story guy should carry a vice grip pliers he could make a make shift clutch lever control off the clutch arm until he could get to a town for proper repairs. I limped a honda goldwing home by using my fingers on the throttle linkage cause the throttle cable broke and I didn't have any tools and the old lady was on behind made for some interesting riding and a very sore finger.
    Norman

  10. deacon

    deacon minor bike philosopher

    Joined:
    Jan 15, 2008
    Messages:
    8,119
    Likes Received:
    0
    Ah I have a set of those little brass tubes with a bolt to make an adjustable end. I have those I use on the end of my throttle cable since I don't have a twist accelerator. I bought mine at the auto parts store. I kept all of the extras since these days you have o buy an assortment.

    Norman I have seen your how to from the other site and it looks good. I noticed on the new cables I bought from the bike store that there are two parts to the ends. there is a smaller bit then the bulge. I think I could just grind off th big blob to make the smaller end on the throttle cable inside the carb.

  11. deacon

    deacon minor bike philosopher

    Joined:
    Jan 15, 2008
    Messages:
    8,119
    Likes Received:
    0
    The vise grip I do carry but it never occurred to me to use it. What I was thinking is tie the clutch the frame to with a slip knot and twine. Get the bike's speed up and pull the string to drop the clutch. use the kill switch to stop the bike, then tie it up again. At the worst you could tie it up and pedal home. I have a very small bungee cord I'm going down right now and put it in the tool bag. Just in case it happens again, I can at least tie the clutch arm to the frame and push it home.

  12. Norman

    Norman LORD VADER Moderator
    Staff Member

    Joined:
    Jan 16, 2008
    Messages:
    2,605
    Likes Received:
    1
    Yes the cable kit comes with a different ends on each end. The throttle cable end that fits in the slide, its important that that end does not come off. That is why I silver solder that end on all my bikes. As far as solder goes silver solder is the way to go I have trouble getting regular solder to stick even with a good acid flux and the cable is galvanized so that could be part of the problem.

  13. Norman

    Norman LORD VADER Moderator
    Staff Member

    Joined:
    Jan 16, 2008
    Messages:
    2,605
    Likes Received:
    1
    Deacon you have the right idea for an emergency road side repair for the clutch. It don't have to be pretty just get you to a place so you can make the proper repairs.
    Norman

  14. Norman

    Norman LORD VADER Moderator
    Staff Member

    Joined:
    Jan 16, 2008
    Messages:
    2,605
    Likes Received:
    1
    I'm going to post a (down and dirty emergency cable end )how to in the next few minutes. I'll start a new post with pictures, I made it out of thing most guys will have in their shop and the only special tools is a tap and a #36 drill bit all done on a vice. I used a 1/4" bolt as well nothing fancy. The problem with using a repair like this is if the cable end pulled out or the cable came apart you will need to carry wire cutters to trim up the shredded cable end and then you might not have enough cable anyway.an option is to carry a length of cable to use. I would carry a cable with a molded end and not mess with the end I made as to many small things to loose but sometimes this end might come in handy. A guy can also skip the threading part and silver solder the end onto the cable skipping all the other stuff.
    Norman

  15. deacon

    deacon minor bike philosopher

    Joined:
    Jan 15, 2008
    Messages:
    8,119
    Likes Received:
    0
    NEW QUESTION

    Is it possible to convert a bicycle wheel to use with only one side support. ie bolt through a frame with no outside rail or folk.

    If so how does one go about it.

  16. nogoodnic

    nogoodnic New Member

    Joined:
    Jan 29, 2008
    Messages:
    509
    Likes Received:
    0
  17. deacon

    deacon minor bike philosopher

    Joined:
    Jan 15, 2008
    Messages:
    8,119
    Likes Received:
    0
    yes that's it exactly.

  18. Bikeguy Joe

    Bikeguy Joe Godfather of Motorized Bicycles

    Joined:
    Jan 8, 2008
    Messages:
    11,529
    Likes Received:
    2
  19. deacon

    deacon minor bike philosopher

    Joined:
    Jan 15, 2008
    Messages:
    8,119
    Likes Received:
    0
    NEW QUESTION.
    What would be the best gasoline engine to use for a friction drive setup. I'm thinking weekwacker with the centrifugal clutch.

    #59 deacon, Feb 23, 2008
    Last edited: Feb 23, 2008
  20. Bikeguy Joe

    Bikeguy Joe Godfather of Motorized Bicycles

    Joined:
    Jan 8, 2008
    Messages:
    11,529
    Likes Received:
    2
    Mine doesn't even have a centrifugal clutch...It's got a lever you throw like an old tractor. You pedal up to about 1 mph, then just throw the lever. Mine will go from 2 mph to 22 with ease. I can even ride it through the yard at a walking pace.

    I believe it's a 32cc Tanaka engine.
