Hmm,
trying to be an "active member" but what do you have to do to post the [im g] xxx [/img] code used on photobucket?

TP



[azbill]

I think after 3 posts, so you should be OK now



[perichbrothers]

I think after 3 posts, so you should be OK now

Cool! Here we go...

So a buddy of mine (sloppy kidricer sin) passed along his MB addiction to us.
For years he had been raving about these things,
and after hemmin and hawin about gettin a slew of craigslist motorcycles,
decided to go the MB route since i've got a ton of old stagnating bike parts,
plus they look like alot of fun.
Also, wanted a project that wasn't as much time intensive as the hot rods and stuff i've got going.
(little did I know so far!!)

So anyway my favorite fat-tire frame is the pre-war shelby,
and coincidentally had the perfect wrecked frame for this build.
A couple months back,
i'd tried to fix the bottom bracket area with a donor girls shelby bike,
but didn't realize the angles weren't the same,
so ditched it before I wasted too much time on it.

Bummer was the earlier 37ish shelby's had a straight downtube,
and the engine doesn't fit in the space correctly.

The later 38ish shelby's hadve a curved downtube.
Since this frame was toast,
figured it was worth customizing it even further.

There was so much brazing on this frame,
it wasn't much fun to weld.
The way I fit the new tube gave it the more welding strength in a cleaner section,
and also more room for the engine.
There was a small insert on the top part.

so the new tube is below the centerline of the BB now...


TP



[perichbrothers]

At first was going to give it the natural flash rust look,
but figured a half-*** paint match was the safer route.
Yeah yeah I didn't grind the welds,
for this one strength is more important than pretty.
(called a 30/30 - 30 mph and 30 feet away)

This is why I think the shelby frame's are so cool.
They invested alot of time in the seat-tube area of the frame,
and as a welder/grinder, I can really appreciate their effort

As common on lots of early bikes,
shelby used a poopload of badges,
(western flyer, hiawatha, shelby flyer, flying cloud etc)
but this one is kinda cool as its a cadillac,
(and schwinn had a lasalle branded bike which makes it a neat competition)

These are my riders,
the black one is 98% stock,
and the red one was alot of my random stuff.
A couple months ago the rims and other chrome was shiny,
but it was all flash rusted,
a perfect donor for the new motor-bike.
(sad to see it torn apart actually but it will be back as a klunker)

I really needed some instant gratification here,
so swapped all the parts to the new frame.
Figured it would be smart to ride it around and make sure it didn't fall apart too!

The thing rode great and straight,
probably the first time it had been ridden in 50 years.

So that was the first night...

TP



[perichbrothers]

So the instructions said that that the build time would take 4-6 hours but obviously didn't pertain to this one!

First was the rear gear,
didn't notice that there were 2 size rubber spacers,
through it on but it got too close to the spokes/tire as it got cinched down.
Ended up doing this twice but oh well...

than the brake lever tweak...

After fitting the engine,
realized the crank wanted to be in the same space.
(that crossbrace repair was done before my time...)

Didn't want to remove the crank so redid it installed...

even though it was a p.i.t.a., it was good enough for now.

TP



[perichbrothers]

after a trial fit,
realized the rear engine mount wasn't going to work either.

so made a custom mount...
(also modified the seat post to angle back)

Spot welded in all the holes,
than brazed it up just in case...

I forgot to take pics of the motormount but you can see it in the below pics...

While I was at it,
figured to change to the older torrington bars,
but they were for a 24" frame so added a couple inches..

TP



[perichbrothers]

So as of the second night,
this is as far as I got.
(Still need to gusset the motormount a bit)

I threw on the kit grips and clutch lever,
which I think are real pos's but at least it will work.

So hopefully tonight some more work will get done.

CHOW

TP



[lobsterboyx]

great mod on that frame! i had one of those laying around for years because the engine wouldent fit in it...



[silverbear]

Nice work. I really like the lines of that frame. Lookin' forward to more pictures...
SB



[bairdco]

it's always fun trying to make a tiny motor fit into an even tiny-er space. l like the way you figured it all out.

the old-timey look is the look for me...

those older bikes were "oven brazed." that's why there's all that leftover brazing allover.



[perichbrothers]

Thanks for the comments guys!

Oven-brazed, never heard of that but sounds like a quicker process than assembly-line jig brazing.
Its neat to see the file marks and imagine a group of guys putting these together.

So decided to throw all the stock stuff on there,
I would have liked to customize a tank and throttle and stuff,
but will have to do that as time allows.
The exhaust has barely a cm of clearance so that will definitely have to change as well.

Oh yeah,
I did find this cool contraption on the side of the house,
it was a massager or something.
The coil fit perfectly...

its kinda goofy but better than a plastic box.

This was after the 2 ten minute warm-ups.
I had to ride it around alot to get it to keep running at first,
but it was alot of fun just doing that.
Now I know why you guys are so stoked on these things!

I cant wait til the break-in period is over.

I'd really like to make the tank, exhaust and some cooler hand controls in the meantime.

CHow

TP



[BarelyAWake]

Ha! I love the coil camo job man!

Not only are ya makin' a sweet lookin' ride, yer doin' it in a matter of days


bairdco's got some competition at last FTW



[perichbrothers]

Hi guys.
First my condolences about these fuzzy cellphone pics.
Its kinda that or 1000 word descriptions - figured fuzzy is better than more rambling.

So,
right now I have an in-shop job,
which makes it really difficult to not get distracted by the shelby-tuner.
But after a super-successful day,
treated myself to a little MB time.
(well I did go out first thing and get some more break-in time but hey)

So this is how it rolled, or was rolling before a midnight coffee...

Basically the stock exhaust with about 1/8" clearance to the front tire...
There's the donor tubing, a wrecked pair of real schwinn stingray apes!

cut ...paste... cut... paste

Now they look like kidricers 1964 schwinn!
It always amazes me when something I shoulda thrown away completes a project.
Those are the scraps leftover on the ground,
it's hard to toss those even, who knows when they'll come in handy!

Also did a little random drillium on the clutch cover.
Probably doesn't help the rattling noises,
but I also cut out the small 6" exit tube in the muffler,
which basically cancels out these periferral noises.
It actually sounds like a mini-bike now.

This is a picture of the customized chain tensioner too.
I wish i'd brazed a reinforcement base on the tubing before attaching the bracketo
(like the motormount one)
The steel is really thin and I shoulda tigged it instead of migging it.
Next time.

Anyway thats my nightly update.
Oh yeah,
Also started on the tank plug but didn't take any pics, maybe tomorrow...

Chow

TP



[silverbear]

BarelyAWake is right... you don't fool around, do you? I like the lines of the exhaust. I also sure do like the background scenery. Model A Ford coupe. Nice. What year? I like yer toys.
SB



[nowramfg]

BarelyAWake is right... you don't fool around, do you? I like the lines of the exhaust. I also sure do like the background scenery. Model A Ford coupe. Nice. What year? I like yer toys.
SB

Looks like a 30 or 31.....the Hemi is the most interesting....and those zoomies/megaphones....



[perichbrothers]

yeah its a 30/31.
Its a customers hot rod.
The exhaust is gonna be a tough project, 4 into 2 megaphones,
but it helps to pay for my own toys!
(i have a 29 roadster pickup, a 40 coupe driver and another 40 project)

TP



[silverbear]

yeah its a 30/31.
Its a customers hot rod.
The exhaust is gonna be a tough project, 4 into 2 megaphones,
but it helps to pay for my own toys!
(i have a 29 roadster pickup, a 40 coupe driver and another 40 project)

TP

Ahhh, the 40's and A's are the best... make my heart go pitapat! I always wanted an A and had a coupe offered to me for free by an X girl friend's father... turned it down as I thought it would be hard to explain to my then first wife. I should have taken it, since my marriage didn't last anyway. A running original A coupe and I said no. One of life's dumbest moments. I did have a 41 pickup and a 41 panel truck with the same nose and running boards as the 40 coupe. Sweet. Those were nice trucks. Now I have 1930's Elgin bicycles and old Schwinns... still like the old stuff and these are more affordable toys, for sure. Sometime take a pix of your Shelby in front of the 40 coupe... if you take requests, that is. It will become an old guy's pinup. Ha!
SB



[silverbear]

Ahhh, the 40's and A's are the best... make my heart go pitapat! I always wanted an A and had a coupe offered to me for free by an X girl friend's father... turned it down as I thought it would be hard to explain to my then first wife. I should have taken it, since my marriage didn't last anyway. A running original A coupe and I said no. One of life's dumbest moments. I did have a 41 pickup and a 41 panel truck with the same nose and running boards as the 40 coupe. Sweet. Those were nice trucks. Now I have 1930's Elgin bicycles and old Schwinns... still like the old stuff and these are more affordable toys, for sure. Sometime take a pix of your Shelby in front of the 40 coupe... if you take requests, that is. It will become an old guy's pinup. Ha!
SB

What am I saying about running boards? I'm getting mixed up with my old MGTD's I think. Now I can't remember if the 40 had running boards or not. Very cool body design anyway. Kind of art deco, now that I think about it.
SB



[perichbrothers]

Hey Silverbear here's the 2 40's...

here's my RPU in work-mode

TP
