Share your custom gas tank!

Discussion in 'Motorized Bicycle Welding, Fabrication and Paintin' started by JaxInsany, Mar 21, 2014.

  1. JaxInsany

    JaxInsany New Member

    Joined:
    May 6, 2013
    Messages:
    60
    Likes Received:
    0
    Hello everyone, my project for the next week is replacing my piece-of-crud, leaky stock gas tank for something more sleek and better functioning. I would love to see pictures of other custom gas tanks that people have made/mounted (particularly tanks mounted behind the seat, mounted under the top tube, or in-tube gas storage)! All designs/suggestions/ideas will be greatly appreciated, thanks!

  2. shenanigans

    shenanigans New Member

    Joined:
    Mar 14, 2014
    Messages:
    11
    Likes Received:
    0
    I just mounted a Crf50 pit bike 1 gallon tank to mine. Its standard location tho. But it is 1 gallon and a dirtbike tank so it looks cool.

  3. The_Aleman

    The_Aleman New Member

    Joined:
    Jul 31, 2008
    Messages:
    2,658
    Likes Received:
    1
    Mine's not exactly custom per se, it's a 6x12" Coyote-Gear spun aluminum tank with end filler, stuffed with anti-slosh foam. Holds about 1 gallon.

    I mounted it using included tank straps under the seat on a trapezoidal bracket I designed, bolted through the caliper brake hole on frame.

    [​IMG]

  4. BarelyAWake

    BarelyAWake New Member

    Joined:
    Jul 21, 2009
    Messages:
    7,209
    Likes Received:
    4
  5. 2door

    2door Moderator
    Staff Member

    Joined:
    Sep 15, 2008
    Messages:
    16,301
    Likes Received:
    25
    I've been real happy with motorcycle tanks. I'm lucky in that there is a MC salvage yard not far from me and they have hundreds, if not a couple of thousand tanks to choose from.
    One of them is from an early 80s vintage Yamaha MX80. It adapted easily to the bike frame. Another is an aftermarket peanut chopper/bobber tank.
    If you like the motorcycle look you might consider them. Both of the tanks I mentioned are 2 gallon capacity. That's a lot of China girl miles on one fill up.

    Tom

  6. culvercityclassic

    culvercityclassic Well-Known Member

    Joined:
    Sep 27, 2009
    Messages:
    3,071
    Likes Received:
    47
    Not sure why this post is in this section but I have a few tanks to share...


    Attached Files:

    Hud likes this.
  7. scotto-

    scotto- Custom 4-Stroke Bike Builder

    Joined:
    Jun 3, 2010
    Messages:
    6,527
    Likes Received:
    5
    A few tanks I've made....

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

    I've done some tanks using the top tube of the bike frame as well......anything but a peanut tank thank you!

  8. bairdco

    bairdco a guy who makes cool bikes

    Joined:
    Aug 18, 2009
    Messages:
    6,333
    Likes Received:
    19
    here's my 6-1/2", half gallon cannonball tank.


    Attached Files:

  9. JaxInsany

    JaxInsany New Member

    Joined:
    May 6, 2013
    Messages:
    60
    Likes Received:
    0
    I love it! Did you purchase the cannonball and drill into it or fabricate it yourself?

  10. shenanigans

    shenanigans New Member

    Joined:
    Mar 14, 2014
    Messages:
    11
    Likes Received:
    0
    Hahahaha boy I read that wromg the first time, I thoughy you said it was a 6 1/2 gallon tank! I was thinking what kind of sorcery is this! I need to slowdown when I read some things.

  11. bairdco

    bairdco a guy who makes cool bikes

    Joined:
    Aug 18, 2009
    Messages:
    6,333
    Likes Received:
    19
    i bought the sphere from an industrial metal supplier and siver soldered a brass bung into it. welded a nut on the bottom for the petcock, and cut and welded 4 tabs to it, so it slips into the custom gusset icut and welded to the frame.

    i could weld a bracket to it to make a behind the seat tank if anyone was interested.

  12. scotto-

    scotto- Custom 4-Stroke Bike Builder

    Joined:
    Jun 3, 2010
    Messages:
    6,527
    Likes Received:
    5
    That would be the BOMB!

    That is a cool looking tank Baird.

  13. JaxInsany

    JaxInsany New Member

    Joined:
    May 6, 2013
    Messages:
    60
    Likes Received:
    0
    I forgot to ask, where did you get the threaded brass bung or did you thread it yourself?

  14. bairdco

    bairdco a guy who makes cool bikes

    Joined:
    Aug 18, 2009
    Messages:
    6,333
    Likes Received:
    19
    it's a port from a cellular antenna and the cap that blocks it off when it's not hooked up. i used to climb towers for telecommunications and ripped it out of a decommisioned antenna.

    i have a bunch of caps but no more ports, and it's some funky thread.

  15. F_Rod81

    F_Rod81 Dealer

    Joined:
    Jan 1, 2011
    Messages:
    1,033
    Likes Received:
    0
    Nice tanks guys!

    I've been waiting for my custom tank for over a month now. I'd love to share pictures of it but I haven't received it :(. I really hope that it wasn't a scam and I'm getting the run around. Communication with the seller has been minimal, but there has been communication. I don't want to have paypal reimburse me... I just want my in frame tank. When I get it I'll post some pics.

    #15 F_Rod81, Apr 7, 2014
    Last edited: Apr 7, 2014
  16. SlowBalt

    SlowBalt Member

    Joined:
    Mar 8, 2010
    Messages:
    759
    Likes Received:
    0
    [​IMG]

    [​IMG]



    [​IMG]

    [​IMG]

    [​IMG]

    #16 SlowBalt, Apr 17, 2014
    Last edited: Apr 17, 2014
  17. SlowBalt

    SlowBalt Member

    Joined:
    Mar 8, 2010
    Messages:
    759
    Likes Received:
    0
  18. scotto-

    scotto- Custom 4-Stroke Bike Builder

    Joined:
    Jun 3, 2010
    Messages:
    6,527
    Likes Received:
    5
    I like pic #3......everything about it....nice tank!

  19. 2door

    2door Moderator
    Staff Member

    Joined:
    Sep 15, 2008
    Messages:
    16,301
    Likes Received:
    25
    Here's a steel and fiberglass tank I built for the Easy Rider Chopper.
    I used a large steel peanut tank and formed a fiberglass shell around it to give it the right shape. Holds 1.2 Gal.

    Tom


    Attached Files:

  20. maniac57

    maniac57 Old, Fat, and still faster than you

    Joined:
    Oct 8, 2011
    Messages:
    4,486
    Likes Received:
    3
    Foam and epoxy resin is the easiest way to sculpt in my opinion.
    Carve the block of foam to shape, glass it with epoxy marine resin and cloth.
    I used to build fiberglass RC boat hulls using this process with great results.
    If you need it hollow, simply dissolve out the foam with lacquer thinner after glassing.
    Messy as hello and fairly deadly chemically to you so read the instructions.
    Very nice work there 2door! Btw...
