54 Schwinn 24'' DX My Next Race Bike

Discussion in 'High Performance Bicycle Engine Tips and Motorized' started by msrfan, Jul 30, 2011.

  1. msrfan

    msrfan Active Member

    Joined:
    Sep 17, 2010
    Messages:
    1,668
    Likes Received:
    0
    Here's some of the stuff I may use for a race bike I'm building. Nothing special. Old cruiser frame and my usual moped parts along with a weed wacker type motor. Haven't totally thought it out yet but it will look similar to my other racer I ran at Willow Springs only the next size down. Trying to break into a smaller class. After seeing scotto racing all day in multiple classes, I should be able to do a couple.


    [​IMG]

  2. Goat Herder

    Goat Herder Gutter Rider

    Joined:
    Apr 28, 2008
    Messages:
    6,251
    Likes Received:
    0
    This looks interesting I like it so far! Nice hubs and everything.:)

  3. MotorBicycleRacing

    MotorBicycleRacing Active Member

    Joined:
    Jul 28, 2010
    Messages:
    5,582
    Likes Received:
    0
    Looking good as usual.
    What are the specs on that motor?
    I presume that it is a 50cc or less 4 stroke?

    Are you going with a belt drive?


  4. msrfan

    msrfan Active Member

    Joined:
    Sep 17, 2010
    Messages:
    1,668
    Likes Received:
    0
    I haven't got that far yet. I'm not sure of the motor specs. Have to check it out. I would like to have a Comet Torque-a-verter on this one but don't know if it has enough power to pull it.

    Looks like I'll have to run with the AGK guys in the 100cc class. It's a little over 50cc. Should be fun.





    #4 msrfan, Jul 30, 2011
    Last edited: Jul 31, 2011
  5. Venice Motor Bikes

    Venice Motor Bikes Custom Builder / Dealer/Los Angeles

    Joined:
    Mar 20, 2008
    Messages:
    6,142
    Likes Received:
    0
    That's a bit of a semi rare frame to motorize, don't you think?

  6. msrfan

    msrfan Active Member

    Joined:
    Sep 17, 2010
    Messages:
    1,668
    Likes Received:
    0
    That's the first thought that came to mind until I got looking at it. The rear fender loop just behind the seat has been somehow ripped out and the tubes leading to the rear dropouts were all bent up. Also being a 24'' helped me decide it would be a good strong choice for my build. I had a 24'' mountain bike frame I was going to use, but it had totally no character. The main reason for going 24'' is because I have these really nice moped drum brake hubs that are 28 spoke. I found some fairly heavy rims and enough of the right size spokes to lace up one wheel. My machinist buddy is shortening the rest of the spokes needed to do the other wheel. They're 1/8'' with large nipples. I plan to clamp the motor in without welding on the frame, so it could be restored to original. It won't be tricked out like some of your bikes, just basic and simple. Thanks for the input. Always welcome.







  7. adb140275

    adb140275 New Member

    Joined:
    Aug 8, 2010
    Messages:
    176
    Likes Received:
    0
    variated would be cool but the comet variator setup would start to variate WAY too soon for that engine to handle it.

    puch forks? maxi or magnum?

  8. Venice Motor Bikes

    Venice Motor Bikes Custom Builder / Dealer/Los Angeles

    Joined:
    Mar 20, 2008
    Messages:
    6,142
    Likes Received:
    0
    If the frames been damaged?, go for it & weld away!!! (^)

  9. msrfan

    msrfan Active Member

    Joined:
    Sep 17, 2010
    Messages:
    1,668
    Likes Received:
    0
    Thanks for the info. Do you think the motor will not have enough rpm, or power, or both? I wish I knew what the forks are from. I've had them forever but not the rest of the moped.





  10. adb140275

    adb140275 New Member

    Joined:
    Aug 8, 2010
    Messages:
    176
    Likes Received:
    0
    the comet will variate at too low of an rpm for the engine to be able to pull it. i dont know if you can get lighter weights for those or not

  11. msrfan

    msrfan Active Member

    Joined:
    Sep 17, 2010
    Messages:
    1,668
    Likes Received:
    0
    I know what you're saying, but wouldn't it depend on my overall drive ratio? I'm starting with 12:1 which it may pull fairly easily. Also, I guess it depends on what rpm the motor builds power. Okay, I'll do some experimenting. Thanks.

  12. MotorBicycleRacing

    MotorBicycleRacing Active Member

    Joined:
    Jul 28, 2010
    Messages:
    5,582
    Likes Received:
    0
    How much over 50 cc?
    It doesn't look like a very large or powerful motor.
    What was it off?
    Side valve or overhead valve?
    What kind of rpm's?
    I really doubt if it has enough power to run a Comet Torque-a-verter.

    It looks like it could run in the 50 cc 4 Stroke Class......

    Is your 5 hp Briggs race bike so hotted up now that you are in the
    <11 hp Class?

  13. msrfan

    msrfan Active Member

    Joined:
    Sep 17, 2010
    Messages:
    1,668
    Likes Received:
    0
    It's a 66cc pushrod motor. Got it in a bunch of stuff a friend gave me. I'll have to check the rpms when I get it going. I don't have a clue the exact hp of my Briggs bike. With the milled head and porting I may have gained a couple. All the internals are totally stock so far.

  14. msrfan

    msrfan Active Member

    Joined:
    Sep 17, 2010
    Messages:
    1,668
    Likes Received:
    0
    I got it up on wheels today, thanks to my machinist buddy, Dan. He cut and threaded the spokes I needed for the rear.




    [​IMG]


    He also made head tube extensions so the longer neck forkes will fit. Then he made me special nuts for the rear axle so I can put it on my stand to tune it before riding.


    [​IMG]

    Got my Comet 20 driver in today. It's almost as big as my motor.




    [​IMG]

    Tomorrow I'll work on the kickstand and front sprocket.

  15. Don P

    Don P New Member

    Joined:
    Sep 1, 2010
    Messages:
    234
    Likes Received:
    0
    HI msrfan
    nice build i like very much. i got a 1957 tornado i picked up last week. could you tell me about the hubs you are using what they came from, how many spoked ect thanks.
    Don P

  16. msrfan

    msrfan Active Member

    Joined:
    Sep 17, 2010
    Messages:
    1,668
    Likes Received:
    0
    Thanks Don. The brake hubs are from old mopeds. I collected them 25 years or so ago, so I can't tell what bike they're from. I was afraid they were going to go to waste because all my other bikes use 36 spoke wheels. Then I got an idea for a 24'' motorbike and most of them had 28 spokes. So I got a nice Schwinn DX frame down from the rafters, where it hung for 15 years, and fitted the hubs and wheels to it. The front forks are also from an unknown moped, as is the fuel tank. I still have lots of work to do, but I think it has some real nice lines. Is your tornado a 24''? Lot's of options for a DIYer out there.

  17. Don P

    Don P New Member

    Joined:
    Sep 1, 2010
    Messages:
    234
    Likes Received:
    0
    msrfan no its a 26" but hay it can be lol.
    Don P

  18. kevinkrg6

    kevinkrg6 New Member

    Joined:
    Jun 3, 2011
    Messages:
    170
    Likes Received:
    0
    Something about bikes like these just look cool....

    Is it the straight fork?

    And is the frame smaller than what those wheels are meant for?

    Can't be just the yellow paint job.....

  19. The_Aleman

    The_Aleman New Member

    Joined:
    Jul 31, 2008
    Messages:
    2,658
    Likes Received:
    0
    Can't wait to see this awesome-looking bike done! :D

  20. msrfan

    msrfan Active Member

    Joined:
    Sep 17, 2010
    Messages:
    1,668
    Likes Received:
    0
    Today I fitted my Comet to motor adapter to my crankshaft.



    [​IMG]

    It fit perfect.


    [​IMG]

    Got my front brake hub to properly fit the forks.

    [​IMG]

    Installed the rear sprocket onto the rear brake hub.


    [​IMG]

    Then I found some stainless acorn nuts for the fork tops.

    [​IMG]


    Going to work on a side stand tomorrow as well as the front pedal sprocket spacing. I'll try to have more photos soon.
